Pulsar Merger LRF dt

XL50 / XP50 / XQ35 PRO

Pulsar Merger LRF thermal biocular

ADVANCED PERFORMANCE IN A CLASSIC DESIGN

Built to appeal to those who appreciate fine European optics, the Pulsar Merger LRF not only looks great but delivers sensational performance, robustness and reliability. It simply oozes quality and enhanced viewing comfort.

It is equally suited to the rigorous demands of professional users such as law enforcement, search and rescue, Coastguard and professional pest management when robustness is a paramount requirement.

The new Merger LRF XL50 is the first release in Pulsar’s HD 1024×768 thermal imaging series.

Pulsar Thermion Duo
Pulsar Merger LRF XQ35 XP50 XL50

Available in three models

Merger LRF XL50



Pulsar Thermion DXP55

Thermal specification

  • Sensor Lynred 640×480 / 17µm / 50Hz
  • Sensitivity NETD <25mK
  • Objective lens F50 / f1.0 precision Germanium
  • Magnification 2x-16x (8x zoom)
  • Field-of-view 12.4° / 21.8m @ 100m (2x)
  • Detection range +/- 1800m

Colour specification

  • Sensor 4k 3840 x 2160
  • Objective lens F35 / f4.32 focus free
  • Magnification 4x-32x (8x zoom)
  • Field-of-view 6.1° / 10.6m @ 100m (4x)

Merger LRF XP50



Pulsar Thermion DXP55

Thermal specification

  • Sensor Lynred 640×480 / 17µm / 50Hz
  • Sensitivity NETD <25mK
  • Objective lens F50 / f1.0 precision Germanium
  • Magnification 2x-16x (8x zoom)
  • Field-of-view 12.4° / 21.8m @ 100m (2x)
  • Detection range +/- 1800m

Colour specification

  • Sensor 4k 3840 x 2160
  • Objective lens F35 / f4.32 focus free
  • Magnification 4x-32x (8x zoom)
  • Field-of-view 6.1° / 10.6m @ 100m (4x)

Merger LRF XQ35 Pro





 Pulsar Thermion Duo DXP50

  • Thermal specification
    • Sensor Lynred 640×480 / 17µm / 50Hz
    • Sensitivity NETD <25mK
    • Objective lens F50 / f1.0 precision Germanium
    • Magnification 2x-16x (8x zoom)
    • Field-of-view 12.4° / 21.8m @ 100m (2x)
    • Detection range +/- 1800m

    Colour specification

    • Sensor 4k 3840 x 2160
    • Objective lens F17 / f4.34 focus free
    • Magnification 2x-32x (16x zoom)
    • Field-of-view 12.4° / 21.8m @ 100m (2x)

Common features and benefits

Tough 30mm tube for easy mounting

Each Thermion Duo can be easily mounted to a variety of firearms in the same way as a classic daylight riflescope. It is waterproof to IPx7 and capable of withstanding heavy recoil, such as .375H&H, 9×63 and 12 gauge rifled slug.

Stream Vision 2 integration with IOS/Android and firmware update



Pulsar Stream Vision 2

Built in Wi-Fi module provides connectivity of thermal imager with Android or iOS smartphones or tablets. The smartphone and thermal imager combination offers a set of unique features such as direct image streaming, downloading and sharing recorded files, firmware update and many other.

Learn more about Stream Vision



Stream Vision 2 integration with IOS/Android and firmware update

Built in Wi-Fi module provides connectivity of thermal imager with Android or iOS smartphones or tablets. The smartphone and thermal imager combination offers a set of unique features such as direct image streaming, downloading and sharing recorded files, firmware update and many other.

Learn more about Stream Vision 1&2

Common specifications

  • Made in Europe by Pulsar
  • Quick-change APS 5T 4900mAh battery for ≤9 hours use
  • HD AMOLED display
  • Withstands 6000J recoil energy (.375H&H, 9.3×64, 12 gauge slug etc)
  • Waterproof IPx7 (immersed in 1 metre of water for 30 mins)
  • Multi-point Picatinny prism mount for ease of mounting
  • Stream Vision 2
  • Size mm 330x57x67
  • Weight 700 grams

Other specifications need to go in a second column preferably. This can also be used for images and videos in necessary.

Accessories

Pulsar batteries

Batteries and chargers

Visit manufacturer’s website for more information

Pulsar Merger LRF range
